G800-A промышленный вибрационный и ударопрочный цифровой датчик угла наклона крана

Код товара: A1005006173153612

Кешбек: 15%

Магазин: АлиКэшбэк20

Пройдите простую регистрацию, чтобы делать покупки выгодно.

Доступные опции:

Цвет:

G800-A

Описание:

Заполнитель

Product descriptions from the supplier

Specification

             The
             G800-A
              series angle sensor adopts MEMS technology and magneto electric induction technology. It uses differential array magnetic sensitive elements and non-contact measurement of the rotating shaft. It senses the parallel magnetic field intensity of the permanent magnet installed at one end of the rotating shaft and processes it through MCU to correct the linearity. , temperature compensation, output signal standardized digital filtering, zero point setting, programmable intelligent control of multiple different slope settings, to achieve the absolute angular position of the output sensor within the range of 0 ~ 360°. Accuracy 0.2°, output RS232, RS485, RS422, CAN, 0-5V, 0.5-4.5V, 0-10V, 4-20mA, 0-20mA optional.
All products have been calibrated, protected against reverse and pulse spike voltages, and tested for long-term aging stability before leaving the factory. Each process is precise and rigorous to ensure reliability under different working conditions and long-term use cycles; it has no contacts and long life. , high resolution, low temperature drift, excellent linearity, precise reset, high frequency response, multiple protections, anti-interference, vibration and impact resistance, suitable for water, oil, gas, vibration and other harsh industrial environments, making it a cost-effective angle sensor. It is also an ideal product for the replacement of contact angle sensors (such as conductive plastic potentiometers, encoders, and angular displacement sensors).

Lead time

                  Quantity (pieces)

                  1 - 500

                  > 500

                  Lead time (days)

                  35

                  To be negotiated

Product performance indicators
parameter	condition	G800-A-90	G800-A-180	G800-A-270	G800-A-360	unit
Measuring range(1)		0~90	0~180	0~270	0~360	°
Temperature drift(2)	-40～85°	0.003	0.003	0.003	0.003	°/ °C
Resolution(3)		0.02	0.02	0.02	0.02	°
Accuracy(4)	-40～85℃	0.2	0.3	0.4	0.6	°
linearity		0.15	0.15	0.15	0.15	%FS
Response time	slow/fast	500/200μS
Power-on start time		0.2s
Output signal(5)(6)		Digital TTL, RS232, RS485, RS422, CAN optional Voltage 0~5V, 0.5-4.5V, 0~10V optional Current 0-20mA, 4-20mA optional


noise		5mV
Shaft rotation direction	Can be set clockwise or counterclockwise
average working hours	≥55000 hours/time
Impact resistance	20000g, 0.5ms, 3 times/axis
Anti-vibration	10grms, 2~2000Hz
Operating temperature	-40～85℃
waterproof level	IP66 (can be customized IP67)
Cable	Standard 1.5 meter length, wear-resistant, oil-proof, wide temperature, shielded cable 4*0.3mm2
weight	120g (excluding packaging box)

            Applications
            ●Motor control: servo system, corner position
●Textile machinery: tension control, shuttle wire diameter
●Valve: angle actuator
●Shipping industry: ship rudder position, hatch position
●Coal mining machinery: coal washer, concentrator, shield machine
●Medical equipment: CT, motor rotation
●Robot: attitude control, boom rotation
●Satellite antenna plane and pitch angle
●Car security control: steering wheel
●Crane, crane, excavator and other engineering equipment


Характеристики:

<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Название бренда</span>	新
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Номер модели</span>	G800-A
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Происхождение</span>	Китай
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Материал</span>	Металл
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Индивидуальное изготовление</span>	Да
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Применение</span>	Датчик скорости
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Выход</span>	Аналоговый сенсор
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Основы</span>	Емкостный датчик
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Тип</span>	Оптоэлектронный датчик
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Название бренда</span>	新
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Номер модели</span>	G800-A
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Происхождение</span>	Китай
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Материал</span>	Металл
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Индивидуальное изготовление</span>	Да
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Применение</span>	Датчик скорости
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Выход</span>	Аналоговый сенсор
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Основы</span>	Емкостный датчик
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Тип</span>	Оптоэлектронный датчик
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Operating Temperature</span>	-40~+85℃
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Output Configuration</span>	RS232,RS485,TTL, RS422,CAN
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Current</span>	4-20mA, 0-20mA, 0~5V, 0.5-4.5V, 0~10V optional
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Voltage Rating</span>	DC 9~36V (5V can be customized)
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Humidity Range</span>	IP67
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Measuring Range</span>	0~360° (optional)
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Resolution</span>	Accuracy 0.2°, resolution 0.02°
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Application</span>	Angle control of various engineering machinery etc
<span class="SnowProductCharacteristics_SnowProductCharacteristicsItem__titleContent__534v9">Product name</span>	MEMS Angle Sensor
